USER'S AND
MAINTENANCE
MANUAL
01/31/2020
Air Compressor : D185T4F-DB
Copyright © 2014, ROTAIR S.P.A. - All rights reserved. This manual is intellectual property of ROTAIR S.P.A.
Its full or partial reproduction is forbidden under any form, on any support and by any means, without the
written authorization by ROTAIR S.P.A.
The draining of the tank must be performed at least 30 minutes after stopping the machine
to allow water to separate from the diesel fuel and settle to the bottom of the tank.
The contaminated fuel from the tank should be disposed of properly and in accordance to the requirements
of hazardous waste disposal in your area.
Remember that the contaminated fuel should not be discarded into the environment.
13.4-8 REPLACING THE DIESEL FUEL FILTER AND PRE-FILTER
For instructions regarding replacing the diesel pre-filter, diesel filter, engine oil,
and other specific filters, refer to the owner's manual of the engine manufacturer
attached to this documentation.
13.4-9 COMPRESSOR OIL FILTER REPLACEMENT
For proper compressor oil filter replacement, follow the directions below:
1) Stop the machine and open the hood of the engine compartment
2) Use an oil filter wrench to remove the filter that needs to be replaced (Figure 13.4-6)
3) Oil the seal of the new filter and hand-tighten it only
4) Start the engine and make sure that there are no oil leaks in the vicinity of the oil filter seal. If there is a
leak, stop the engine and correct the leak.
Figure 13.4-6 Compressor oil filter
WARNING: The used oil filter contains hazardous materials and needs to be
treated as hazardous waste; therefore, it must be disposed of
according to the requirements for hazardous waste disposal in your
area.
WARNING: Replace the compressor oil filter after 500 hours or after a long storage
period (9-12 months), whichever comes first.
