USER'S AND
MAINTENANCE
MANUAL
Date:
01/31/2020
Code
MAN D185T4F-DB
ENG
Air Compressor : D185T4F-DB
Revision
03
Copyright © 2014, ROTAIR S.P.A. - All rights reserved. This manual is intellectual property of ROTAIR S.P.A.
Its full or partial reproduction is forbidden under any form, on any support and by any means, without the
written authorization by ROTAIR S.P.A.
Page
26/59
8 ELECTRICAL EQUIPMENT OF THE MACHINERY
WARNING: any action on the electrical system must be performed by qualified personnel.
8.1 Operator's instrument panel and controls
1) Air pressure gauge
2) Hour counter
3) START button
4) ON/OFF switch
5) Fuel level indicator
Figure 8.1-1 Instrument panel and controls
1
4
3
2
5
