Rotex HPSU 6-8X User Manual

10 x Technical data
117
FA ROTEX HeatPumpSolarUnit - Part 2 - 05/2009
Backup Heater (BH)
Type 3V3
Voltage supply
Phases 1
Voltage V 230
Voltage range V Voltage
10%
Frequency Hz 50
Power consumption A 13
Mains connection 3G
Order number Indoor Module incl.
Backup Heater
RKHBH008AA3V3 RKHBX008AA3V3 RKHBH016AB3V3 RKHBX016AB3V3
Type 6V3
Voltage supply
Phases 1
Voltage V 230
Voltage range V Voltage
10%
Frequency Hz 50
Power consumption A 26
Mains connection 3G
Order number Indoor Module incl.
Backup Heater
RKHBH008AA6V3 RKHBX008AA6V3 RKHBH016AB6V3 RKHBX016AB6V3
Type 6WN
Voltage supply
Phases 3
Voltage V 400
Voltage range V Voltage
10%
Frequency Hz 50
Power consumption A 8.7
Mains connection 4G
Order number Indoor Module incl.
Backup Heater
RKHBH008AA6WN RKHBX008AA6WN RKHBH016AB6WN RKHBX016AB6WN
Type 9WN
Voltage supply
Phases 3
Voltage V 400
Voltage range V Voltage
10%
Frequency Hz 50
Power consumption A 13
Mains connection 4G
Order number Indoor Module incl.
Backup Heater
RKHBH008AA9WN RKHBX008AA9WN RKHBH016AB9WN RKHBX016AB9WN
Tab. 10-2 Basic data for Indoor Modules
1) In connection with Outdoor Module RRHQ006 ..V
2) In connection with Outdoor Module RRHQ007 ..V
3) In connection with Outdoor Module RRHQ008 ..V
4) In connection with Outdoor Module RRHQ011 ..V/W
5) In connection with Outdoor Module RRHQ014 ..V/W
6) In connection with Outdoor Module RRHQ016 ..V/W
7) With a reference distance of 1 m (see section 10.1.3 and Tab. 10-3).
a) with condensation water drip tray installed
DB Measured with dry thermometer
WB Measured with wet bulb thermometer
6-8 kW 11 to 16 kW
Unit RKHBH008 RKHBX008 RKHBH016 RKHBX016
