Samsung OH55A User Manual

92
Support
Software Update
MENU mSupportSoftware UpdateENTER E
The Software Update menu lets you upgrade your product software to the latest version.

Be careful not to turn off the power until the upgrade is complete. The product will turn off and on
automatically after completing the software upgrade.

When you upgrade software, all video and audio settings you have made will return to their default settings.
We advise you to write down your settings so that you can easily reset them after the upgrade.
Update Now
Update the software to the latest version.

Current version: This is the software version already installed in the product.
Contact Samsung
MENU mSupportContact SamsungENTER E
You can view the address of the Samsung website, the call center phone number, your product's model
number, software version, Open Source License and other information.

Go to Contact Samsung and find the product Model Code and Software Version.
Terms & Conditions
MENU mSupportTerms & ConditionsENTER E
View and set the privacy policy for MagicInfo and other services.

Make sure that the product is connected to the network.
Reset All
MENU mSupportReset AllENTER E
This option returns all the current settings for a display to the default factory settings.
Chapter 10

Samsung OH55A Specifications

General

Cables included	AC
Purpose	Commercial
HDCP version	2.2
Operating hours (hours/days)	24/7
International Protection (IP) code	IP56
Internal memory	2.5 GB
Processor cores	4
Processor model	A72
Processor family	ARM Cortex
Processor frequency	1.7 GHz
Audio formats supported	AC3
Video formats supported	AVC, AVS+, H.263, H.264, HEVC, MPEG1, MPEG2, MPEG4, VC-1, VP8, VP9
Internal storage capacity	8 GB
Operating system installed	Tizen
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Placement supported	Outdoor
Bezel width (bottom)	24.9 mm
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	10 - 100 %
Package depth	230 mm
Package width	1358 mm
Package height	845 mm
Package weight	52600 g
AC input voltage	100 - 240 V
Heat dissipation	1809 BTU/h
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	274 W
Ethernet LAN (RJ-45) ports	1
Haze rate	0 %
Pixel pitch	0.63 x 0.63 mm
Response time	8 ms
Display diagonal	55 \
Display brightness	3500 cd/m²
Vertical scan range	24 - 75 Hz
Horizontal scan range	23 - 136 kHz
LED backlighting type	Edge-LED BLU
Contrast ratio (dynamic)	100000:1
Contrast ratio (typical)	5000:1
Display number of colors	16.78 million colors
Active display area (W x H)	1209.6 x 680.4 mm

Weight and Dimensions

Depth	85 mm
Width	1260.6 mm
Height	731.4 mm
Weight	46100 g
