Samsung SC-MX20 User Manual

English_69
SETTING THE PLAY OPTION
You can play all movie images continuously or play the selected movie images only.
You can also set the repeat option for all movie images.
1. Slide the POWER switch downward to turn on the memory camcorder.
Set the appropriate storage media.
(SC-MX20C/MX20CH/MX20E/MX20EL/MX20ER only)
(If images were recorded on a memory card, insert the memory card.)
2. Press the MODE button.
➥
page 22
Switches to Movie Play mode ( ).
The recorded movie images are displayed in thumbnail index view.
3. Press the MENU button.
Press the Control button ( / ) to select "Play Option".
4. Press the Control button ( / ) to select an option, and then press the
OK button.
item contents
"Play All" Plays back from the selected image to the last image.
"Play One" The selected movie image will be played.
"Repeat All" All movie images will be played repeatedly.
"Repeat One" The selected movie image will be played repeatedly.
5. Press the MENU button to exit the menu.
During playback, the selected item is applied.
While the menu or thumbnail image screen is displayed, pressing the
Recording start/stop button will move to the Movie Record mode.
In general, use of functions both in thumbnail display and full image
display employs the same method, while their detailed options appear
to be different.
•
•
•
•
•
•
•
•

Samsung SC-MX20 Specifications

General

Filter size	30 mm
Digital zoom	1200 x
Optical zoom	32 x
Image stabilizer	Yes
Focal length range	1.6 - 4.3 mm
Sensor type	CCD
Total megapixels	11.2 MP
Compatible operating systems	Windows 7, Vista, XP SP2
Display diagonal	2.7 \
Maximum video resolution	720 x 480 pixels
Image formats supported	JPG
Still image resolution(s)	800 x 600
Audio formats supported	AAC
Camera shutter speed	1/60 - 1/10000 s
PictBridge	No
USB 2.0 ports quantity	1
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Battery type	IA-BP85ST

Weight and Dimensions

Depth	60 mm
Width	125 mm
Height	60.5 mm
Weight	270 g
