SICK deTec4 C4C-EV03030A10000 User Manual

12 Technical data
12.1 Data sheet
Table 9: General system data
Minimum Typical Maximum
Protective field height, depending on
t
ype
300mm to 2,100mm, 150-mm steps
Resolution (detection capability) 30mm
Sensing sensing range, type-specific
1)
Receiver with low sensing range 3.8m
Receiver with medium sensing
r
ange 6m
Receiver with high sensing range 12m 15m
Minimum distance between sender and receiver
Receiver with low sensing range 1.8m
Receiver with medium sensing
r
ange 3.8m
Receiver with high sensing range 0m
Protection class
2)
III (IEC 61140)
Enclosure rating IP65 (IEC60529)
IP67 (IE
C 60529)
Supply voltage U
V
a
t the device
3)

4)
 19.2V 24V 28.8V
Residual ripple
5)
±10%
Synchronization Optical
Type Type 4 (IEC61496-1)
Category Category 4 (ISO 13849-1)
Performance level
6)
PL e (ISO 13849–1)
Safety integrity level
6)
SIL 3 (IEC 61508)
SIL claim limit
6)
SILCL 3 (IEC62061)
PFH
D
(me
an probability of a danger‐
ous failure per hour)
3.7 × 10
-9
T
M
(mis
sion time) 20years (ISO 13849-1)
Safe status when a fault occurs At least one OSSD is in the OFF state.
Power-up delay of sender and
r
eceiver after supply voltage is
applied
2s
1)
If the protective fields are very wide, there is a possibility that all four alignment quality LEDs will not light
up e
ven when alignment is excellent.
2)
SELV/PELV safety extra-low voltage.
3)
The external voltage supply must be capable of bridging a brief power failure of 20ms as specified in
IEC60204-1. Suitable power supply units are available as accessories from SICK.
4)
A fuse rated maximum 4A shall be installed in the 24VDC power supply circuit to the device in order to
limit the available current.
5)
Within the limits of U
V
.
6)
For more detailed information on the exact configuration of your machine, please contact your relevant
SIC
K subsidiary.
TECHNICAL DATA 12
8024467/1GWF/2022-11-11 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes
51
Subject to change without notice
