SICK deTec4 C4C-EV03030A10000 User Manual

Part Type code Part number
Female connector, straight, 10m c
able, flying
leads
YF2A15-100UB5XLEAX 2095619
Female connector, straight, 15m cable, flying
leads
YF2A15-150UB5XLEAX 2095620
Female connector, straight, 20m cable, flying
leads
YF2A15-200UB5XLEAX 2095614
Female connector, straight, 30m cable, flying
leads
YF2A15-300UB5XLEAX 2095621
Female connector, angled, 2m c
able, flying
leads
YG2A15-020UB5XLEAX 2095772
Female connector, angled, 5m cable, flying
leads
YG2A15-050UB5XLEAX 2095773
Female connector, angled, 10m c
able, flying
leads
YG2A15-100UB5XLEAX 2095774
Table 24: Ordering information, connection cable (replacement of existing devices)
2)
Part Type code Part number
Connection cable, M12, 5-pin to M12, 8-pin DSL-1285GM25034KM1 2070987
Connection cable, M12, 5-pin to M26, 7-pin DSL-6187GM25034KM1 2070988
Connection cable, M12, 5-pin to M26, 12-pin DSL-6182GM25034KM1 2070989
Table 25: Distributor ordering information
Part Type code Part number
T distributor, 5-pin DSC-1205T000025KM0 6030664
Table 26: Resistance terminal ordering information
Part Part number
Resistance terminal, 2.15kΩ 2073807
Table 27: Ordering information for power supply
Part Type code Part number
Output 24VDC, 50W (2.1A), voltage supply
NE
C Class 2, SELV, PELV, input 120V AC …
240VAC
PS50WE24V 7028789
Output 24VDC, 95W (3.9A), voltage supply
NEC Class 2, SELV, PELV, input 100V AC …
120V/220V AC … 240VAC
PS95WE24V 7028790
14.4 Alignment aid
Table 28: Alignment aid ordering information
Part Part number
AR60 laser alignment aid 1015741
Adapter 4070854
2)
Ambient oper
ating temperature: Down to –30°C with fixed installation
14 A
CCESSORIES
60
O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/1GWF/2022-11-11 | SICK
