4.3 Terminal and block diagrams
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
100 Manual, 09/2016, A5E35306440-AB
Interconnection overview of outputs
Combined interconnection of the technology channels
The following table provides you with an overview of the possible interconnections of the
front connectors X11 and X12 to allow you to correctly divide the available inputs between
the possible technology channels HSC, PWM and PTO. This overview is a combination of
interconnection options of technology channels for HSC, PWM and PTO.
Configurable
as standard
DQ for chan-
nel
Configura-
ble as
PWM
output for
channel
Configurable
as PTO
output A for
channel
1)
Configurable
as PTO
output B for
channel
2)
Configurable
as "Drive
enable output"
for channel
Can be
used as
HSC-
DQ1 for
channel
X11 1 DQ0
Standard DQ0 PWM1 [PTO 2/3/4]
2 DQ1
3 DQ2
4 DQ3
Standard DQ3 [PTO 1/2/3/4]
5 DQ4
6 DQ5
7 DQ6
8 DQ7
Standard
*
*
*
*
To Next Page
