Siemens CPU 1518-4 PN/DP ODK User Manual

CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
Manual, 09/2016, A5E35306440-AB
128
Technical specifications
7
Technical specifications of the CPU 1512C-1 PN
6ES7512-1CK00-0AB0
General information
Product type designation
CPU 1512C-1 PN
Hardware functional status
FS03
Firmware version
V2.0
Engineering with
STEP 7 TIA Portal can be configured/integrated
as of version
V14
Configuration control
Via data record
Yes
Display
Screen diagonal (cm)
3.45 cm
Operator controls
Number of keys
6
Mode selector
1
Supply voltage
Type of supply voltage
24 V DC
Valid range, low limit (DC)
19.2 V; 20.4 V DC for supply of digital in-
puts/outputs
Valid range, high limit (DC)
28.8 V
Reverse polarity protection
Yes
Power and voltage failure backup
Power/voltage failure backup time
5 ms; refers to the supply voltage at the CPU unit
Input current
Current consumption (rated value)
0.8 A; digital on-board I/O is supplied separately
Inrush current, max.
1.9 A; rated value
I²t
0.34 A²s
Digital inputs
From the load voltage L+ (no load), max.
20 mA; per group
Digital outputs
From the load voltage L+, max.
30 mA; per group, without load
Output voltage
Rated value (DC)
24 V
Encoder supply
Number of outputs
2; a common 24 V encoder supply for each 16
digital inputs
