Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Functions 14 Dec 2011
4.7.9 Chilled / heated ceiling and radiator applications
For chilled / heated ceiling and radiator,
 set the corresponding basic application
 disable the fan (P52)
The following applications are available:
4.7.10 Compressor applications (general)
For compressor applications,
 set the corresponding basic application
 disable the fan (P52) or set the fan speed (P53)
The following applications are available:
 Minimum on/off time: P48 / P49
 Fan operation: P52 (0 = disabled, 1 = enabled)
 Fan speed: P53 (1 = 1-speed, 2 = 3-speed)
Application for
chilled / heated ceiling, radiator
Set basic application See
section
Sequences
Chilled / heated ceiling with
changeover
2-pipe 4.7.3
H (
\ )
C ( / )
Chilled / heated ceiling & el. heater
(cooling only: disable el. heater
via P13)
2-pipe & electric heater 4.7.4
El. H +
H (
\ \ )
El. H + C (
\ / )
C ( / )
Chilled / heated ceiling & radiator
2-pipe & radiator 4.7.5
H + rad
( \ r\ )
Rad + C ( r\ / )
Chilled ceiling and radiator
4-pipe 4.7.6
H + C
( \ / )
Chilled / heated ceiling, 2-stage
2-stage heating or cooling 4.7.8
H + H
( \ \ )
C + C ( / / )
Application for
chilled / heated ceiling, radiator
Set basic application See
section
Sequences
1-stage compressor
2-pipe 4.7.3
H (
\ )
C ( / )
1-stage compressor & el. heater
(cooling only: disable el. heater
via P13)
2-pipe & electric heater 4.7.4
El. H + H (
\ \ )
El. H + C (
\ / )
C ( / )
1-stage compressor
for heating and cooling
4-pipe 4.7.6
H + C
( \ / )
1-stage compressor with reversing
valve (for details, see below)
4-pipe 4.7.6
H + C
( \ / )
2-stage compressor
2-stage heating or cooling 4.7.8
H + H
( \ \ )
C + C ( / / )
