Siemens RDG100 User Manual

9 / 66
Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Use 14 Dec 2011
2.4 Accessories
Description Product no.
Data
Sheet
Changeover mounting kit (50 pcs / package) ARG86.3 3009
Adapter plate 120 x 120 mm for 4“ x 4“ conduit boxes ARG70 3009
Adapter plate 112 x 130 mm for surface wiring ARG70.2 3009
2.5 Ordering
Product no. Stock number Designation
RDG100 S55770-T158 Room thermostat
RDG100T S55770-T159 Room thermostat, with timer
RDG100T/H S55770-T235 Room thermostat, with timer, landscape housing
RDG110 S55770-T160 Room thermostat
RDG140 S55770-T161 Room thermostat
RDG160 S55770-T162 Room thermostat
Order the IRA211 infrared remote control separately.
Order valve actuators separately.
3 Use
The RDG1… room thermostats are designed for use with the following types of
system:
Fan coil units via ON/OFF or modulating control outputs:
 2-pipe system
 2-pipe system with electric heater
 2-pipe system and radiator / floor heating
 4-pipe system
 4-pipe system with electric heater
 2-stage heating or cooling system
Chilled / heated ceilings (or radiators) via ON/OFF or modulating control
outputs:
 Chilled / heated ceiling
 Chilled / heated ceiling with electric heater
 Chilled / heated ceiling and radiator / floor heating
 Chilled / heated ceiling, 2-stage cooling or heating
Heat pumps with dx type equipment:
 1-stage compressor for heating or cooling
 1-stage compressor for heating or cooling with electric heater
 1-stage compressor for heating or cooling and radiator / floor heating
 1-stage compressor for heating and cooling with reversing valve
 2-stage compressor for heating or cooling
