43 / 66
Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Functions 14 Dec 2011
4.10 Multifunctional input, digital input
The thermostat has 2 multifunctional inputs X1 and X2 and a digital input D1.
A sensor type NTC like the QAH11.1 (AI, analog input) or a switch (DI, digital input)
can be connected to the input terminals. The functionality of the inputs can be
configured via parameters P38 for X1, P40 for X2, and P42 for D1.
# Function of input Description Type
X1/X2
Type
DI
0 Not used No function. -- --
1 External / return
air temperature
Sensor input for external room temperature sensor or
return air temperature sensor to acquire the current
room temperature, or floor heating temperature
sensor to limit the heating output.
Note: The room temperature is acquired by the built-in
sensor if the floor temperature limitation function is
enabled via parameter P51.
AI
2 Heating / cooling
changeover
Sensor input for automatic heating / cooling
changeover function.
A switch can also be connected rather than a sensor
(switch closed = cooling, see section 4.6).
AI/(DI)
DI
3 Operating mode
switchover
Digital input to switch over the operating mode to
Economy.
If the operating mode switchover contact is active,
user operations are ineffective and “OFF” is displayed.
DI DI
4 Dewpoint monitor Digital input for a dewpoint sensor to detect
condensation. Cooling is stopped if condensation
occurs.
DI DI
5 Enable electric
heater
Digital input to enable / disable the electric heater via
remote control.
DI DI
6 Fault Digital input to signal an external fault
(example: dirty air filter).
If the input is active, “ALx” is displayed
(Alarm x, with x = 1 for X1, x = 2 for X2, x = 3 for D1).
Note: Fault displays do not influence the thermostat's
operation. They merely represent a visual signal.
DI DI
Operational action can be changed between normally open (NO) and normally
closed (NC) via parameter P39, P41 (or P43 if it is a digital input).
Each input X1, X2 or D1 must be configured with a different function (1…5).
Exception: 1, 2 or 3 inputs can be configured as alarm inputs (6).
X1 is factory-set to “External sensor” (1), X2 to “Heating / cooling changeover” (2),
and D1 to operating mode changeover (3).
If a multifunctional input is configured as analog: "Err" will be displayed when the
output is out of range (0...49 °C), open or shorted.
For more detailed information, refer to section 4.5 “Applications”.
For inputs X1, X2, or D1, one physical switch can be used for up to 20
thermostats (parallel connection).
Caution! DO NOT mix X1 / X2 (mains potential) and D1.
For sensors on inputs X1, X2, or D1, the cable length is max. 80 m.
Installation note:
