Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Functions 14 Dec 2011
4.15.2 Parameters of the "Expert level
with diagnostics and test"
Parameter
Name Factory
setting
Range
RDG100 RDG100T RDG100T/H RDG110 RDG140 RDG160 Dependencies
Expert level
P30 P-band / switching differential in heating
mode
2 K 0.5…6 K
      
P31 P-band / switching differential in cooling
mode
1 K 0.5…6 K
      
P32 P-band / switching differential for radiator 2 K 0.5…6 K
     
Appl
P33 Dead zone in Comfort mode 2 K 0.5…5 K
     
Appl
P34 Setpoint differential (w
D
) 2 K 0.5…5 K
     
Appl
P35 Integral action time 5 min 0…10 min
  
x
 
P46,
P47
P36 Heating / cooling changeover cooling
(X1/X2)
16 °C 10…25 °C
     
P38,
P40
P37 Heating / cooling changeover heating
(X1/X2)
28 °C 27…40 °C
     
P38,
P40
P38 Functionality of X1 1 = external
sensor
0 = --- (no function)
1 = room temp ext / ret air temp (AI)
2 = H/C changeover (AI/DI)
3 = operating mode contact [DI)
4 = dewpoint sensor (DI)
5 = enable electric heater (DI)
6 = fault input (DI)

0..6

0..6

0..6

0..6

0..6

0..6

P39 Operating action of X1 if digital input 0 (NO) 0 = normally open / open
1 = normally closed / closed
     
P38
P40 Functionality of X2 2 = H/C
changeover
0 = --- (no function)
1 = room temp ext / ret air temp (AI)
2 = H/C changeover (AI/DI)
3 = operating mode contact [DI)
4 = dewpoint sensor. (DI)
5 = enable electric heater (DI)
6 = fault input (DI)

0..6

0..6

0..6

0..6

0..6

0..6
P41 Operating action of X2 if digital input 0 (NO) 0 = normally open / open
1 = normally closed / closed
     
P40
P42 Functionality of D1 3 = operating
mode
changeover
0 = --- (no function)
2 = H/C changeover (DI)
3 = operating mode contact [DI)
4 = dewpoint sensor (DI)
5 = enable electric heater (DI)
6 = fault input (DI)

0..6

0..6

0..6

0..6

0..6

0..6

P43 Operating action of D1 if digital input 0 (NO) 0 = normally open / open
1 = normally closed / closed
     
P42
P44 Running time of Y1/Y2 output
(only with modulating PI control)
150 s 20…300 s
  
x x x
P46
P45 Running time of Y3/Y4 output
(only with modulating PI control)
150 s 20…300 s
  
x x x
P47
P46 Output Y1/Y2 (if not parameterized as 3-
pos.)
ON/OFF (1) 1 = 2-position
2 = PWM
  
x x x
Appl
P46 Load current of electric heater on Y21 (for
adaptive temperature compensation
1 A 1...5 A x x x

x x
Appl
P47 Output Y3/Y4 (if not parameterized as 3-
pos.)
ON/OFF (1) 1 = 2-position
2 = PWM
  
x x x
Appl
P48 Min. output on time
2-position control output
1 min. 1...20 min.
   
x x
P46
P49 Min. output off time
2-position control output
1 min. 1...20 min.
   
x x
P47
P50 Purging function (only when changeover
with local sensor is selected)
OFF OFF: Not active
1…5 min: Active with selected duration
     
P38,
P40
P51 Floor heating limit temperature OFF OFF, 10...50 °C
     
P38,
P40
 Parameter available
 Parameter not available
 P46, P47: Setting to 2-position or 3-position is made with DIP switches 4 and 5.
 P46 to compensate for heat dissipation of the el. heater relay in RDG110.
 If no sensors or switches are connected, it is not necessary to disable the inputs
(P38, P40 or P42 = no function), the thermostat recognizes if a sensor is
connected (but diagnostic shows "Err").
