Siemens RDG100 User Manual

49 / 66
Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Functions 14 Dec 2011
4.15.1 Parameters of the "Service level"
Parameter
Name Factory setting Range
RDG100 RDG100T RDG100T/H RDG110 RDG140 RDG160 Dependencies
Service level
P01 Control sequence With 2-pipe /
2-stage:
1 = cooling only
With 4-pipe:
4 = H/C
0 = heating only
1 = cooling only
2 = H/C changeover manually
3 = H/C changeover automatically
4 = heating and cooling
      
P02 Operating mode profile (operating mode
button)
1 1 = (Auto) - Comfort – Protection
2 = (Auto) - Comfort - Economy - Prot
      
3 = Comfort – Protection *)
4 = Comfort – Economy – Protection *)
x
 
x x x
P03 Fan mode selection 0 0 = Auto – Manual
1 = Manual
2 = Auto – Manual – Prot
     
P52
P04 Selection of °C or °F 0 (°C) 0 = degrees Celsius (°C)
1 = degrees Fahrenheit (°F)
      
P05 Sensor calibration (internally, externally) 0 K – 3...3 K
      
P06 Standard temperature display 0 0 = room temperature
1 = setpoint
      
P07 Display info line
(2nd line of LCD)
0 0 = --- (no display)
1 = °C and °F
0..1 x x 0..1 0..1 0..1
P08 Comfort setpoint 21 °C 5...40 °C
      
P09 Min. setpoint for Comfort mode 5 °C 5...40 °C
      
P10 Max. setpoint for Comfort mode 35 °C 5...40 °C
      
P11 Economy heating setpoint 15 °C OFF, 5 ... WcoolE-saving;
(WcoolE-saving = 40 °C max.)
      
P12 Economy cooling setpoint 30 °C OFF, WHeatEco ... 40 °C;
(WHeatEco = 5 °C min.)
      
P13 Electric heater in cooling mode ON ON: Enabled
OFF: Disabled
     
Appl
P14 Button lock function 0 0 = unlocked
1 = auto locked
2 = manual locked
      
P15
**)
Fan stage in dead zone (Comfort) 0 0 = disabled
1 = stage 1 (heating and cooling)
2 = stage 1 (cooling only)
      
 Parameter available
 Parameter not available
*) RDG100T/H or RDG100T with SW V7.2 and higher / device index E
**) P15 available with SW V7.2 and higher / device index E
Parameter display depends on selected application and function
Note
