Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Summary 14 Dec 2011
 2 multifunctional inputs, freely selectable for:
– Operating mode switchover contact (keycard)
– Automatic heating / cooling changeover sensor
– External room temperature or return air temperature
– Dewpoint sensor
– Electric heater enable
– Fault input
 Advanced fan control function, i.e. fan kick, fan start, selectable fan operation
(enable, disable or depending on heating or cooling mode)
 Purge function together with 2-port valve in a 2-pipe changeover system
 Reminder to clean filters
 Floor heating temperature limit
 Reloading factory settings for commissioning and control parameters
 7-day time program: 8 programmable timers to switch over between Comfort
and Economy mode (RDG100T, RDG100T/H)
 Infrared remote control (RDG100T, RDG100T/H)
2.2 Types and features
Features
Number of control outputs
Product no.
Operating voltage
ON/OFF PWM 3-pos
DC
0..10 V
Time program
Backlit LCD
Infrared receiver
1)
ECM Fan
2)
RDG100
AC 230 V
3
3)
2
3)
2
3)

RDG100T
AC 230 V
3
3)
2
3)
2
3)

5)
 
RDG100T/H
AC 230 V
3
3)
2
3)
2
3)

5)
 
RDG110
AC 230 V
2
4)

RDG140
AC 24 V
2

RDG160
AC 24 V
2
 
1) Infrared remote control must be ordered as a separate item
2) ECM fan output DC 0…10 V
3) ON/OFF, PWM or 3-position (triac outputs)
4) Relay output (SPDT)
5) Can be disabled via P02 (SW V7.2 and higher / device index E)
