Technical speci󹪝cations
Design of the mounting bracket for four-point mounting
Dimensions (W x H x D) 43.6 x 43.6 x 18.3mm (1 height unit)
Plate thickness 1.5mm
Bending radii 1.5mm
Surface of the housing Stainless steel X6CR17
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C) > 12.6 years
1)
Wiring rules
Note the wiring rules (Page65).
2)
Ambient temperature with SFP
The maximum ambient temperature during operation depends on the operating elevation
and the installed plug-in transceivers, see also the section "SFP plug-in transceiver (Page36)"
in the "Accessories" section.
3)
Restriction when operating with plug-in transceivers of this type
A maximum of two plug-in transceivers of this type may be used.
4)
Derating
The derating values depend on the maximum ambient temperatures during operation up to
2000 m.
5)
Degree of protection
The degree of protection was not examined in the context of UL certi󹪝cation.
6)
Degree of protection
The degree of protection was not examined in the context of FM certi󹪝cation.
9.3.2 100 to 240V AC / 110 to 250V DC device versions
The following technical speci󹪝cations apply to the 100 to 240VAC / 110 to 250VDC device
versions of the SCALANCE XR524-8WG.
Technical speci󹪝cations
Connection to Industrial Ethernet
Electrical connectors Quantity 24
Connector RJ45 jack
Transmission speed 10 / 100 / 1000 Mbps
Properties Half/full duplex, MDI‑X pinning
Slots for plug-in transceiver
(SFP+)
Quantity 8
Connector SFP/ SFP+ plug-in transceiver
Transmission speed 1 / 10 Gbps
Technical speci󹪝cations
9.3SCALANCE XR524-8WG
SCALANCE XR-500
106 Operating Instructions, 07/2023, C79000-G8976-C692-01
