Technical speci󹪝cations
9
9.1 SCALANCE XR502-32
9.1.1 24VAC/DC device version
The following technical speci󹪝cations apply to the 24VAC/DC version of the SCALANCE
XR502-32.
Technical speci󹪝cations
Connection to Industrial Ethernet
Electrical connectors Quantity 2
Connector RJ45 jack
Transmission speed 1 / 2.5 / 5 / 10 Gbps
Properties Half/full duplex, MDI‑X pinning
Slots for plug-in transceivers (SFP) Quantity 24
Connector SFP plug-in transceiver
Transmission speed 100 / 1000 Mbps
Slots for plug-in transceiver
(SFP+)
Quantity 8
Connector SFP/ SFP+ plug-in transceiver
Transmission speed 1 / 10 Gbps
Diagnostics interface
Serial interface Quantity 1
Connector USB Type B
Signaling contact
1)
Quantity 1
Design Spring-loaded terminal block, 2-pin
Permitted voltage range 24VDC
Load rating Max. 100 mA
Button Quantity 1
Con󹪝guration interface
Removable data storage medium Quantity 1
Product name Siemens Con󹪝guration and License PLUG (CLP)
Connection to power supply
SCALANCE XR-500
Operating Instructions, 07/2023, C79000-G8976-C692-01 91
