Siemens SCALANCE XR-500 User Manual

Technical speci󹪝cations
Design of the mounting bracket for four-point mounting
Dimensions (W x H x D) 43.6 x 43.6 x 18.3mm (1 height unit)
Plate thickness 1.5mm
Bending radii 1.5mm
Surface of the housing Stainless steel X6CR17
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C) 6GK5534-2TR00-3AR3 > 8.3 years
6GK5534-2TR00-4AR3 > 10.2 years
1)
Wiring rules
Note the wiring rules.
2)
Ambient temperature with SFP
The maximum ambient temperature during operation depends on the operating elevation
and the installed plug-in transceivers, see also the section "SFP plug-in transceiver" in the
"Accessories" section.
3)
Restriction when operating with plug-in transceivers of this type
A maximum of two plug-in transceivers of this type may be used.
4)
Derating
The derating values depend on the maximum ambient temperatures during operation up to
2000 m.
5)
Degree of protection
The IP20 degree of protection was not examined in the context of UL certi󹪝cation.
See also
Wiring rules (Page65)
Accessories (Page36)
9.5 Mechanical stability (in operation)
The devices listed in the scope of validity meet the following requirements for mechanical
stability during operation:
IEC 60068-2-27 shock IEC 60068-2-6 vibration
• 15 g, 11 ms duration
• 6 shocks per axis
• 10 - 58 Hz: 0.075 mm
• 85 - 150Hz: 1 g
• 1 octave/min, 20 sweeps
Technical speci󹪝cations
9.5Mechanical stability (in operation)
SCALANCE XR-500
Operating Instructions, 07/2023, C79000-G8976-C692-01 115
