Technical speci󹪝cations
Plate thickness 1.5mm
Bending radii 1.5mm
Surface of the housing Stainless steel X6CR17
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C) > 8.3 years
1)
Wiring rules
Note the wiring rules (Page65).
2)
Ambient temperature with SFP
The maximum ambient temperature during operation depends on the operating elevation
and the installed plug-in transceivers, see also the section "SFP plug-in transceiver (Page36)"
in the "Accessories" section.
3)
Restriction when operating with plug-in transceivers of this type
A maximum of two plug-in transceivers of this type may be used.
4)
Derating
The derating values depend on the maximum ambient temperatures during operation up to
2000 m.
5)
Degree of protection
The IP20 degree of protection was not examined in the context of UL certi󹪝cation.
9.4 SCALANCE XR526-8
9.4.1 24VAC/DC device version
The following technical speci󹪝cations apply to the 24 V AC/DC version of the SCALANCE XR526-8.
Technical speci󹪝cations
Connection to Industrial Ethernet
Electrical connectors Quantity 24 2
Connector RJ45 jack RJ45 jack
Transmission speed 10 / 100 / 1000 Mbps 1 / 2.5 / 5 / 10 Gbps
Properties Half/full duplex, MDI‑X pinning
Slots for plug-in transceiver
(SFP+)
Quantity 8
Connector SFP/ SFP+ plug-in transceiver
Transmission speed 1 / 10 Gbps
Diagnostics interface
Technical speci󹪝cations
9.4SCALANCE XR526-8
SCALANCE XR-500
Operating Instructions, 07/2023, C79000-G8976-C692-01 109
