Installation
5.2 Installing a switch
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
109
Note
Wall mounting of a rack device
For wall mounting of a rack device (R), use suitable fittings such as a mounting bracket.
Wall mounting of the IE Switch X-300EEC
To mount the IE Switch X-300EEC on a wall, you require an additional securing bracket. You
will find the dimensions for a suitable securing bracket in section Graphics (Page 279).
5.2.4 19" rack mounting
WARNING
Use of approved components
• Use only approved 19" cabinets.
• Use only supplied mounting brackets.
There are several ways of fixing the mounting brackets depending on the mounting
position required.
19" rack mounting
19" rack mounting is possible for all rack devices identified by (XR).
Refer to the technical specifications, Installation options table for each product group. The
rack device (R) is installed using two mounting brackets fitted to the front. After fitting the two
mounting brackets, the rack device can then be installed in a 19" cabinet.
CAUTION
Do not cover the ventilation grilles
During installation, select a mounting position so that the ventilation grilles are always free
to achieve adequate cooling. In the standard position, the ventilation grilles are on the top,
bottom and sides of the housing.
If you install more than one rack device, make sure that the permitted ambient conditions
are met for all devices in the rack.
