11.7 SFP dimension drawings
SCALANCE X-300
300 Operating Instructions, 02/2012, A5E01113043-12
11.7 SFP dimension drawings
Note
The followi
ng dimension drawings are available for the SFP product group.
Note
All dimensi
ons are ± 0.2 mm unless otherwise specified.
Figure 11-28 SFP dimension drawing
