Description of the device
4.2 Product groups
SCALANCE X-300
58 Operating Instructions, 02/2012, A5E01113043-12
4.2.1.12 SCALANCE X320-3LD FE product characteristics
Possible attachments
The SCALANCE X320-3LD FE has 20 RJ-45 jacks and 1 FO port (for multimode fiber) and
2 FO ports (for single mode fiber) for the connection of end devices or other network
segments.
Figure 4-12 SCALANCE X320-3LD FE
Column 1 2 3 4 5 6
P1 P5 P9 P13 P17 P21 *
2
)
P2 P6 P10 P14 P18 P22 *
2
)
P3 P7 P11 P15 P19 P23 *
2
)
Port number
P4 P8 P12 P16 P20
Connection type
electrical
No marking → Fast Ethernet port
*
1
) marking → gigabit Ethernet port
Connection type
optical
*
2
) marking → Fast Ethernet port
*
3
) marking → gigabit port
