11.8 X-300M PoE dimension drawings
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
301
11.8 X-300M PoE dimension drawings
All dimensions in the drawings are in millimeters.
Figure 11-29 X308-2M PoE: Front view
