Technical specifications
8.3 X-300M technical specifications
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
167
8.3.4 Other properties
Table 8- 28 Switching properties
Max. number of learnable addresses 8 000
Aging time 30 sec
Switching technique Store and forward
Latency 5 μs
Table 8- 29 Reconfiguration times for redundancy mechanisms
Redundancy mechanism Reconfiguration times
HSR 300 ms
Standby link 300 ms
MRP 200 ms
Table 8- 30 Mean time between failure (MTBF)
MTBF > 40 years
1)
1)
The time information applies to the mounting device without media modules.
Note
The IE Switches X-300 support "full wire speed switching" complying with IEEE 802.3 on all
ports. The number of packets therefore depends on the packet length.
