Technical specifications
8.5 Technical specifications for X-300EEC
SCALANCE X-300
176 Operating Instructions, 02/2012, A5E01113043-12
8.5.1 Construction, installation and environmental conditions
Table 8- 47 Construction
Device version
(power supply)
Dimensions (W x H x D) Weight Degree of
protection
1 24 VDC power supply unit
• Without clip:
60 × 125 × 123 mm
• With clip:
216 × 203 × 99 mm
1 800 g IP30
2 x 24 VDC power supply
units
• Without clip:
60 × 125 × 123 mm
• With clip:
216 × 203 × 99 mm
2 030 g IP30
1 x power supply unit
100 to 240 VAC / 60 to 250
VDC
• Without clip:
60 × 125 × 123 mm
• With clip:
216 × 203 × 99 mm
1 850 g IP30
2 x power supply units
100 to 240 VAC / 60 to 250
VDC
• Without clip:
60 × 125 × 123 mm
• With clip:
216 × 203 × 99 mm
2 120 g IP30
Table 8- 48 Installation options
Installation options
• DIN rail
• S7-300 standard rail
1)
• Wall
2)
• 19" rack
3)
1)
Possible only with adapter (must be provided by installers).
2)
Wall mounting possible with suitable wall support.
3)
With mounting support
Table 8- 49 Permitted ambient conditions
Storage/transport
temperature
Operating temperature Max. relative
humidity in
operation at 25 °C
Max. ambient temperature
at operating altitude
-40 °C to +70 °C -40 °C to +70 °C
1)
< 95 % (no
condensation)
Max. 65 °C as of 2 000 m
Max. 60 °C as of 3 000 m
1)
The IE Switch was type tested for 16 h at +85 °C.
