Siemens SIMATIC ET 200SP HA User Manual

Connection
4
4.1 Terminal blocks
De󹪝nition
The terminal blocks provide the process terminals (push-in terminals) for components to be
connected such as devices.
Description
The following terminal blocks are available for the I/O module:
Article No. Color Description
6DL1193-6TP00-0DH1 Light gray For single mode
"Enable new potential group"
6DL1193-6TP00-0BH1 Dark gray For single mode
"Use potential group of the left module"
6DL1193-6TP00-0DP0 Light gray Double-width terminal block with L+ potential distributor
For single operation only
"Enable new potential group"
6DL1193-6TP00-0BP0 Dark gray Double-width terminal block with L+ potential distributor
For single operation only
"Use potential group of the left module"
6DL1193-6TP00-0DN0 Light gray Double-width terminal block with M potential distributor
For single operation only
"Enable new potential group"
6DL1193-6TP00-0BN0 Dark gray Double-width terminal block with M potential distributor
For single operation only
"Use potential group of the left module"
6DL1193-6TP00-0DF1 Black Only for redundant interconnection of two F-AI 8xI 2-/4-wire HART HA F-
modules
"Mo potential group"
F-AI 8xI 2-/4-wire HART HA
Equipment Manual, 09/2021, A5E50557845-AA 15

Siemens SIMATIC ET 200SP HA Specifications

General

Category	I/O Systems
System	SIMATIC ET 200SP HA
Mounting	DIN rail
Protection Rating	IP20
Communication Protocol	PROFINET
Redundancy	Yes
Hot Swapping	Yes
Modularity	Modular
Power Supply	24 V DC
Temperature Range	-40 to 70 °C
Product Type	Distributed I/O
Number of I/O modules	Up to 64
Redundancy Type	system redundancy
Operating Temperature	-40 to 70 °C
Storage Temperature	-40 to 70 °C
Relative Humidity	5% to 95% (non-condensing)
Vibration Resistance	IEC 60068-2-6
Shock Resistance	According to IEC 60068-2-27
Mounting Type	DIN rail
