7.2.3 Channel status / fault LEDs
De󹪝nition
The channel status and channel fault LEDs provide you information about the status and faults
of the channels.
Description
The channel status and channel fault LEDs indicate the following:
Channel status
LED
Channel fault
LED
Meaning
O󹪜 O󹪜
Channel disabled or module switched o󹪜.
On O󹪜
Channel activated and no channel diagnostics pending.
O󹪜 On
Channel activated and channel diagnostics or module diagnos‐
tics pending.
7.2.4 Channel status/DIAG/Channel fault LEDs
De󹪝nition
The combination of the Channel status, DIAG and Channel fault LEDs provide you information
about status and error information of the module.
Description
The combination of the status and fault displays of the Channel status, DIAG and Channel fault
LEDs is as follows:
Channel sta‐
tus LED
DIAG LED Channel fault
LED
Meaning
O󹪜 Flashes All On
• The PROFIsafe address is di󹪜erent from the con󹪝g‐
ured PROFIsafe address.
• Module fault/defect
• Fault on all channels
Flashes Flashes O󹪜
Identi󹪝cation of the module for assignment of the
PROFIsafe address
Displays, alarms and messages
7.2 LEDs
F-AI 8xI 2-/4-wire HART HA
Equipment Manual, 09/2021, A5E50557845-AA 63
