6.11 Calculation of the remaining supply voltage at the sensor
To ensure the function of the connected sensor, the remaining supply voltage U
min
must be
greater than/equal to the minimum supply voltage of the sensor.
To calculate the remaining supply voltage on the sensor, determine the following voltages
depending on the wiring scheme used:
• Determine the minimum supply voltage (UV
min
):
Power supply unit e.g. for SITOP 24 V ± 2%
UV
min
= UV – [Tolerance] = 24 V – 2% = 23.5 V
(Voltage drop on the supply line to the I/O module was neglected).
• Calculate the maximum voltage drop on the signal line (U
line
):
For example, for copper cable 500 m with ∅ = 0.5 mm²; at I
max
= 25 mA
`ǵ
`NN

`NNN

ǵ
`N
3
$BCMF

U
line
= 35.7 Ω × 25 mA = 0.9 V
• Calculate the voltage drop (U
Ri
) at the input resistance "Ri" of the I/O module:
– With Ri
max
= 150 Ω; at I
max
= 25 mA
U
Ri
= 150 Ω × 25 mA = 3.8 V
– In a high-availability application case, the voltage of the Z diodes used in the redundant
terminal block (U
Z
= 6.2 V) must also be considered with a tolerance of 5%.
U
Z_6V2
= U
Z
+ Tolerance = 6.2 V + 5% = 6.5 V
• Determine the voltage drop at the sensor supply U
sensor supply
:
U
sensor supply
= 1.2 V
Calculation examples
Example for the calculation of the remaining supply voltage (U
min
) on a 2-wire transmitter in an
application case with no high-availability:
• U
min
= UV
min
– U
line
– U
Ri
– U
sensor supply
• U
min
= 23.5 V – 0.9 V – 3.8 V – 1.2 V = 17.6 V
Example for the calculation of the remaining supply voltage (U
min
) on a 2-wire transmitter in an
application case with high availability:
• U
min
= UV
min
– U
line
– U
Z_6V2
– U
Ri
– U
sensor supply
• U
min
= 23.5 V – 0.9 V – 6.5 V – 3.8 V – 1.2 V = 11.1 V
Applications of the F-I/O module
6.11 Calculation of the remaining supply voltage at the sensor
F-AI 8xI 2-/4-wire HART HA
60 Equipment Manual, 09/2021, A5E50557845-AA
