Siemens SIMATIC ET 200SP HA User Manual

7.3 Interrupts
De󹪝nition
The fail-safe analog input module F-AI 8xI 2-/4-wire HART HA supports diagnostic interrupts and
maintenance messages.
A diagnostic interrupt is an alarm that reports activated events of a device status to the system
operator with the appropriate operator authorization (maintenance and service).
Diagnostic interrupts are used by the I/O module to output both diagnostic messages and
maintenance events.
Diagnostic interrupts
The F-module generates a diagnostic interrupt for each diagnostic message described in section
"Diagnostic messages (Page 67)".
The following table provides an overview of the diagnostics interrupts of the F-module. The
diagnostics interrupts are assigned either to one channel or to the entire F-module.
Diagnostic interrupts of F-AI 8xI 2-/4-wire HART HA
Diagnostic interrupt Error code E󹪜ective range
of diagnostic in‐
terrupt
Con󹪝gurable
Overtemperature 5
H
F-module No
Wire break 6
H
Channel Yes
High limit exceeded 7
H
Channel No
Low limit violated 8
H
Channel No
Parameter error 10
H
F-module No
Supply voltage missing 11
H
F-module No
Communication error 13
H
F-module No
Channel/component temporarily unavailable 1F
H
F-module No
Mismatch of safety destination address (F_Dest_Add) 40
H
F-module No
Safety destination address not valid (F_Dest_Add) 41
H
F-module No
Safety source address not valid (F_Source_Add) 42
H
F-module No
Safety watchdog timer value is 0 ms (F_WD_Time) 43
H
F-module No
Parameter F_SIL exceeds SIL from speci󹪝c device application 44
H
F-module No
Parameter F_CRC_Length does not match the generated values 45
H
F-module No
Version of F-parameter set incorrect 46
H
F-module No
CRC1 fault 47
H
F-module No
Device-speci󹪝c diagnostic information, see manual 48
H
F-module No
Inconsistent iParameters (iParCRC error) 4B
H
F-module No
F_Block_ID not supported 4C
H
F-module No
Transmission error: Inconsistent data (CRC error) 4D
H
F-module No
Transmission error: Timeout (monitoring time 1 or 2 expired) 4E
H
F-module No
Module is defective 100
H
F-module No
Watchdog tripped 103
H
F-module No
Displays, alarms and messages
7.3 Interrupts
F-AI 8xI 2-/4-wire HART HA
Equipment Manual, 09/2021, A5E50557845-AA 65
