7.2 LEDs
7.2.1 DIAG LED
De󹪝nition
The DIAG LED provides you diagnostic information.
Description
The diagnostic display of the DIAG LED is as follows:
DIAG LED Meaning
O󹪜
The power supply of the ET 200SP HA is disrupted or switched o󹪜.
󹪞ashes
Module is not con󹪝gured.
On
Module parameters are assigned. No diagnostic message is pending.
󹪞ashes
Module parameters are assigned. At least one diagnostic message is
pending.
/
Alternately 󹪞ashing
Module is waiting for user acknowledgment.
7.2.2 MT LED
De󹪝nition
The MT LED provides maintenance information.
Description
The MT LED indicates the following maintenance status:
MT LED Meaning
O󹪜
No maintenance is required.
On
Maintenance is required. At least one maintenance event has occurred.
Displays, alarms and messages
7.2 LEDs
F-AI 8xI 2-/4-wire HART HA
62 Equipment Manual, 09/2021, A5E50557845-AA
