Siemens SIMATIC IPC227G User Manual

Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC227G
34 Operating Instructions, 07/2022, A5E50059933-AC
Procedure
Insert the metal plate of the strain relief into the
second last groove on the left and right sides.
Secure the strain relief with an M3 × 6 setscrew on the
left and right sides respectively.
Secure the connection cables with cable ties to the
cable strain relief.
3.3.7 Installing Ethernet connector strain relief
The Ethernet connector strain relief prevents accidental loosening of the Ethernet connector
from the device. The Ethernet connector strain relief is available as an accessory.
Procedure
Unscrew the marked retaining screw.
Insert the metal plate of the Ethernet connector strain
relief into the second groove.
