Technical specifications
7.4 Technical data
SIMATIC IPC227G
Operating Instructions, 07/2022, A5E50059933-AC
71
7.4 Technical data
7.4.1 General technical specifications
General technical specifications
Weight without mounting brackets
Approx. 1.4 kg
Power supply
1
• 24 V DC (19.2 to 28.8V)
• Rated output power: 30W
Power consumption (DC)
• 40%~60% full load, 24 V DC at 85% efficiency
• Pout ≥ 6W, 24 V DC at 70% efficiency
• Pout < 6W, 24 V DC at 50% efficiency
Current consumption
Max. 1.9 A at 24 V
Noise emission
< 55 dB(A) according to DIN 45635-1
Degree of protection
IP40 in accordance with IEC 60529
Protection class
Protection class I in accordance with IEC 61140
Overvoltage Category
II
Pollution Degree
2
Quality assurance
In accordance with ISO 9001
1
: The device may only be connected to a 24 V DC power supply which meets the requirements of a
safe extra-low voltage (SELV) or protective extra-low voltage (PELV) in accordance with IEC/EN/DIN
EN/UL 61010-2-201.
Electromagnetic compatibility
Radiation Emission (Enclosure port)
in accordance with IEC 61000-6-3
+ A1/ CAN/CSA-CISPR 22:10
• 30 to 230 MHz: 30 dB(µV/m) Quasi-peak (10 m distance)
• 230 to 1000 MHz: 37 dB (µV/m) Quasi-peak (10 m distance)
• 1 to 3 GHz: 70 dB (µV/m) Peak; 50 dB (µV/m) Average (3 m
distance)
• 3 to 6 GHz: 74 dB (µV/m) Peak; 54 dB (µV/m) Average (3 m
distance)
Immunity with regard to
conducted interference on the
supply lines
• ± 2 kV (5 kHz /100 kHz) in accordance with IEC 61000-4-4;
Burst
• ± 1kV line to line, ±2 kV line to earth in accordance with IEC
61000-4-5; Surge
