Maintaining and repairing the device
6.4 Reinstalling the operating system
SIMATIC IPC227G
Operating Instructions, 07/2022, A5E50059933-AC
55
Unscrew the marked two spring screws with a T8
screwdriver on the motherboard.
Unscrew the marked two screws on the power module
and unscrew the marked other five screws with a T10
screwdriver on the motherboard.
Unplug the connector between power module and
motherboard.
Press the retaining clips outward in the direction of the
arrows to unlock the memory socket.
Pull out the memory module from the socket.
6.4 Reinstalling the operating system
Information on installation of the operating system is available on the Internet:
• Microsoft® Windows® 10
(https://support.industry.siemens.com/cs/ww/en/view/109749498)
