5 Configuring Communication Connections
A-140
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
5.7.1 Specifying the Local Connection Endpoint
General Tab
This tab of the Properties dialog displays general connection parameters that
identify the local connection endpoint.
Figure 5-18 Layout of the “General” Tab in the Properties Dialog for UDP Connections
