Siemens Simatic S7-1500 User Manual

Parameters/address space
5.4 Measurement types and measuring ranges of the analog on-board I/O
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
Manual, 09/2016, A5E35306440-AB
109
5.4
Measurement types and measuring ranges of the analog
on-board I/O
Introduction
The analog on-board I/O is set to voltage measurement type and measuring range ±10 V by
default for the inputs on channels 0 to 3. By default, channel 4 is set to resistance measuring
type and measuring range 600 Ω. If you want to use another measurement type or
measuring range, change the parameter settings of the analog on-board I/O with STEP 7
(TIA Portal).
Disable unused inputs to prevent disturbances that cause incorrect behavior (e.g. triggering
of a hardware interrupt).
Measurement types and measuring ranges
The following table shows the measurement types, the measuring range and the possible
channels.
Table 5- 3 Measurement types and measuring range
Measurement type
Measuring range
Channel
Voltage 0 to 10 V
1 to 5 V
±5 V
±10 V
0 to 3
Current 4WMT
(4-wire measuring transducer)
0 to 20 mA
4 to 20 mA
±20 mA
0 to 3
Resistance 150 Ω
300 Ω
600 Ω
4
Thermal resistor RTD Pt 100 Standard/Climate
Ni 100 Standard/Climate
4
Deactivated
-
-
The tables of the input ranges, overflow, underrange, etc. can be found in the appendix .

Siemens Simatic S7-1500 Specifications

General

Protection Class	IP20
Programming Language	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Memory	Work memory and load memory (integrated or external memory card)
I/O Modules	Digital I/O, Analog I/O, Technology modules, Communication modules
Safety Integrated	Yes (with fail-safe CPUs and modules)
Redundancy	CPU redundancy possible with specific CPU types
Temperature Range	0°C to 60°C (horizontal installation)
Digital Inputs	Scalable through digital input modules
Digital Outputs	Scalable through digital output modules
Analog Inputs	Scalable through analog input modules
Analog Outputs	Scalable through analog output modules
Backplane	Integrated backplane for module connection
Real-time clock	Integrated real-time clock
CPU Type	Various models available (e.g., CPU 1511-1 PN, CPU 1513-1 PN, CPU 1515-2 PN, CPU 1517-3 PN, CPU 1518-4 PN/DP)
