Siemens Simatic S7-1500 User Manual

CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
Manual, 09/2016, A5E35306440-AB
128
Technical specifications
7
Technical specifications of the CPU 1512C-1 PN
6ES7512-1CK00-0AB0
General information
Product type designation
CPU 1512C-1 PN
Hardware functional status
FS03
Firmware version
V2.0
Engineering with
STEP 7 TIA Portal can be configured/integrated
as of version
V14
Configuration control
Via data record
Yes
Display
Screen diagonal (cm)
3.45 cm
Operator controls
Number of keys
6
Mode selector
1
Supply voltage
Type of supply voltage
24 V DC
Valid range, low limit (DC)
19.2 V; 20.4 V DC for supply of digital in-
puts/outputs
Valid range, high limit (DC)
28.8 V
Reverse polarity protection
Yes
Power and voltage failure backup
Power/voltage failure backup time
5 ms; refers to the supply voltage at the CPU unit
Input current
Current consumption (rated value)
0.8 A; digital on-board I/O is supplied separately
Inrush current, max.
1.9 A; rated value
I²t
0.34 A²s
Digital inputs
From the load voltage L+ (no load), max.
20 mA; per group
Digital outputs
From the load voltage L+, max.
30 mA; per group, without load
Output voltage
Rated value (DC)
24 V
Encoder supply
Number of outputs
2; a common 24 V encoder supply for each 16
digital inputs

Siemens Simatic S7-1500 Specifications

General

Protection Class	IP20
Programming Language	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Memory	Work memory and load memory (integrated or external memory card)
I/O Modules	Digital I/O, Analog I/O, Technology modules, Communication modules
Safety Integrated	Yes (with fail-safe CPUs and modules)
Redundancy	CPU redundancy possible with specific CPU types
Temperature Range	0°C to 60°C (horizontal installation)
Digital Inputs	Scalable through digital input modules
Digital Outputs	Scalable through digital output modules
Analog Inputs	Scalable through analog input modules
Analog Outputs	Scalable through analog output modules
Backplane	Integrated backplane for module connection
Real-time clock	Integrated real-time clock
CPU Type	Various models available (e.g., CPU 1511-1 PN, CPU 1513-1 PN, CPU 1515-2 PN, CPU 1517-3 PN, CPU 1518-4 PN/DP)
