Parameter data records
B.3 Structure of a data record for output channels of the analog on-board I/O
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
Manual, 09/2016, A5E35306440-AB
155
Table B- 6 Limits for thermal resistor Pt 100 Standard and Pt 100 Climate
Thermal resistor
Pt 100 Standard
Pt 100 Climate
°C °F K °C °F K
9999
18319
12731
15499
31099
---
High limit
-2429 -4053 303 -14499 -22899 --- Low limit
Table B- 7 Limits for thermal resistor Ni 100 Standard and Ni 100 Climate
Thermal resistor
Ni 100 Standard
Ni 100 Climate
°C
°F
K
°C
°F
K
2949
5629
5681
15499
31099
---
High limit
-1049
-1569
1683
-10499
-15699
---
Low limit
B.3
Structure of a data record for output channels of the analog
on-board I/O
Assignment of data record and channel
The parameters for the 2 analog output channels are located in data records 64 and 65 and
are assigned as follows:
● Data record 64 for channel 0
● Data record 65 for channel 1
