Siemens Simatic S7-1500 User Manual

Technology functions
3.1 High-speed counters
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
40 Manual, 09/2016, A5E35306440-AB
3.1.2
Configuring the high-speed counters
3.1.2.1
General
You configure the high-speed counters (HSC) in STEP 7 (TIA Portal).
The functions are controlled by the user program.
Reference
A detailed description of configuring the counting and measuring functions can be found in:
● S7-1500, ET 200MP, ET 200SP Counting, measurement and position detection
(http://support.automation.siemens.com/WW/view/en/59709820
) function manual
● in the STEP 7 online help under "Using technology functions > Counting, measuring and
position detection > Counting, measuring and position detection (S7-1500)"
A detailed description of configuring Motion Control be found in:
● S7-1500 Motion Control (http://support.automation.siemens.com/WW/view/en/59381279
)
function manual
● in the STEP 7 online help under "Using technology functions > Motion Control > Motion
Control (S7-1500)"
3.1.2.2
Assignment of the control interface of the high-speed counters
The user program uses the control interface to influence the behavior of the high speed
counter.
Note
Operation with High_Speed_Counter technology object
The High_Speed_Counter technology object is available for high
-speed counting mode. We
therefore recommend
use of the High_Speed_Counter technology object instead of the
control interface/feedback interface for controlling the high speed counter.
For information on configuring the technology object and programming the associated
instruction, refer to the S7
-1500, ET 200MP, ET
200SP Counting, measurement and position
detection (
http://support.automation.siemens.com/WW/view/en/59709820) function manual.

Siemens Simatic S7-1500 Specifications

General

Protection Class	IP20
Programming Language	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Memory	Work memory and load memory (integrated or external memory card)
I/O Modules	Digital I/O, Analog I/O, Technology modules, Communication modules
Safety Integrated	Yes (with fail-safe CPUs and modules)
Redundancy	CPU redundancy possible with specific CPU types
Temperature Range	0°C to 60°C (horizontal installation)
Digital Inputs	Scalable through digital input modules
Digital Outputs	Scalable through digital output modules
Analog Inputs	Scalable through analog input modules
Analog Outputs	Scalable through analog output modules
Backplane	Integrated backplane for module connection
Real-time clock	Integrated real-time clock
CPU Type	Various models available (e.g., CPU 1511-1 PN, CPU 1513-1 PN, CPU 1515-2 PN, CPU 1517-3 PN, CPU 1518-4 PN/DP)
