Maintenance and service
5.5 SIMOTION CompactFlash Card
SIMOTION D410
Commissioning Manual, 02/2012
193
Note
When upgrading SINAMICS drive units (e.g. SINAMICS Integrated) only the p parameters
(setting parameters) are loaded into the upgraded project. The r parameters (monitoring
parameters) are not loaded.
The r parameters in the drive unit are derived or calculated from an automatic subsequent
parameterization and must therefore be uploaded to the project.
To do this, execute "Load CPU/drive unit to PG".
If the upload cannot be performed, this can lead to inconsistencies in the drive
parameterization dialog boxes.
5.5 SIMOTION CompactFlash Card
5.5.1 Replacing the CompactFlash Card
Prerequisite
Note
Always power down the unit before you insert or remove the CompactFlash Card!
The SIMOTION D410 is in a de-energized state when all the LEDs are OFF.
Procedure
How to replace the CompactFlash Card:
1. Shut down the power supply.
2. Remove the CompactFlash Card from the plug-in slot on the SIMOTION D410.
To do this, grasp the gripping cavity between your thumb and forefinger and pull the card
out.
3. Insert the new CompactFlash Card into the card slot. Push it in all the way with slight
pressure until it engages. The insertion direction of the CompactFlash Card is identified
by an arrow on the card and a matching arrow on the slot.
The properly inserted card does not protrude from the SIMOTION D410 housing.
4. Restart the power supply.
