6.2 PLC user interface signals
6-122
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
Axis actual value and distances to go
5700 ... 5704
Signals from axis/spindle [r]
Data block Interface PLC –––––> MMC
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
570x0000 Axis actual value (REAL)
570x0004 Axis distance to go (REAL)
