Siemens SINUMERIK 802C User Manual

Technical Appendix
6.1 List of machine and setting data
6-95
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
208 $MM_USER_CLASS_WRITE_ZOA
Decimal User class Write settable zero offset Immediately 2/3
0 3 0 7 Byte
210 $MM_USER_CLASS_WRITE_SEA
Decimal User class Write setting data Immediately 2/3
0 3 0 7 Byte
216 $MM_USER_CLASS_WRITE_RPA
Decimal User class Write R parameters Immediately 2/3
0 3 0 7 Byte
217 $MM_USER_CLASS_SET_V24
Decimal User class Set V24 Immediately 2/3
0 3 0 7 Byte
219 $MM_USER_CLASS_DIR_ACCESS
Decimal User class access directory Immediately 2/3
0 3 0 7 Byte
277 $MM_USER_CLASS_PLC_ACCESS
Decimal User class access PLC project Immediately 2/3
0 3 0 7 Byte
278 $MM_NCK_SYSTEM_FUNC_MASK
Decimal Option data to enable system–specific functions POWER ON 2/2
0 0 0 15 Byte
280 $MM_V24_PPI_ADDR_PLC
Decimal PPI address of the PLC POWER ON 3/3
0 2 0 126 BYTE
281 $MM_V24_PPI_ADDR_NCK
Decimal PPI address of the NCK POWER ON 3/3
0 3 0 126 BYTE
282 $MM_V24_PPI_ADDR_MMC
Decimal PPI address of the HMI POWER ON 3/3
0 4 0 126 BYTE
283 $MM_V24_PPI_MODEM_ACTIVE
Decimal Modem active Immediately 3/3
0 0 0 1 BYTE
284 $MM_V24_PPI_MODEM_BAUD
Decimal Modem baud rate Immediately 3/3
0 7 5 9 BYTE
285 $MM_V24_PPI_MODEM_PARITY
Decimal Modem parity Immediately 3/3
0 0 0 2 BYTE
