Siemens SINUMERIK 802C User Manual

Technical Appendix
6.1 List of machine and setting data
6-98
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
31000
ENC_IS_LINEAR
- Direct measuring system (linear scale) (encoder no.) POWER ON
_always 0 *** *** BOOLEAN 2/7
31010
ENC_GRID_POINT_DIST
mm Division period for linear scales (encoder no.) POWER ON
_always 0.01 0.0 plus DOUBLE 2/7
31020
ENC_RESOL
- Encoder markings per revolution (encoder no.) POWER ON
_always 2048 0.0 plus DWORD 2/7
31030
LEADSCREW_PITCH
mm Pitch of leadscrew POWER ON
_always 10.0 0.0 plus DOUBLE 2/7
31040
ENC_IS_DIRECT
- Encoder mounted directly to the machine (encoder no:) POWER ON
_always 0 *** *** BOOLEAN 2/7
31050
DRIVE_AX_RATIO_DENOM
- Denominator load gearbox (control parameter no.): 0...5 POWER ON
_always 1, 1, 1, 1, 1, 1 1 2147000000 DWORD 2/7
31060
DRIVE_AX_RATIO_NUMERA
- Numerator load gearbox (control parameter set no.): 0...5 POWER ON
_always 1, 1, 1, 1, 1, 1 1 2147000000 DWORD 2/7
31070
DRIVE_ENC_RATIO_DENOM
- Denominator resolver gearbox (encoder no.) POWER ON
_always 1 1 2147000000 DWORD 2/7
31080
DRIVE_ENC_RATIO_NUMERA
- Numerator resolver gearbox (encoder no.) POWER ON
_always 1 1 2147000000 DWORD 2/7
31090
JOG_INCR_WEIGHT
mm, de-
grees
Evaluation of an increment with INC/handwheel RESET
32000
MAX_AX_VELO
mm/min,
rev/min
Maximum axis velocity NEW CONF
_always 10000. 0.0 plus DOUBLE 2/7
32010
JOG_VELO_RAPID
mm/min,
rev/min
Rapid treverse in jog mode RESET
_always 10000. 0.0 plus DOUBLE 2/7
32020
JOG_VELO
mm/min,
rev/min
Jog axis velocity RESET
_always 2000. 0.0 plus DOUBLE 2/7
32070
CORR_VELO
% Axis velocity for handwheel override, ext. ZO, cont. dressing, distance control RESET
_always 50 0.0 plus DWORD 2/7
32100
AX_MOTION_DIR
- Traversing direction (not control direction) POWER ON
_always 1 -1 1 DWORD 2/7
