Siemens SITOP PSU200M 6EP1333-3BA10 User Manual

SITOP modular 1ph/2ph
Manual, 04.2018, C98130-A7548-A1-4-7629
37
Technical data
6
Note
Technical data is applicable for a rated input voltage of 230
V AC, rated load and 25 °C
ambient temperature (if nothing else is specified).
6.1
Input
6EP1333-3BA10
(24 V/5 A)
6EP1334-3BA10
(24 V/10 A)
6EP1336-3BA00
(24 V/20 A)
6EP1337-3BA00
(24 V/40 A)
Input
1-phase and 2-phase AC
Rated voltage U
in rated
120 - 230/230 - 500 V
120 - 230/230 - 500 V
120/230 V
120/230 V
Voltage range
• Remark
85 - 264/176 - 550 V
Setting via selector
switch on the device;
starting from
U
in
> 90/180 V
Derating for -25 to
0 °C:
Starting with max.
500 V
85 - 264/176 - 550 V
Setting via selector
switch on the device;
starting from
U
in
> 90/180 V
Derating for -25 to
0 °C:
Starting with max.
500 V
85 - 132/176 - 264 V
Setting via selector
switch on the device;
starting from
U
in
> 93/183 V
85 - 132/176 - 264 V
Setting via selector
switch on the device;
starting from
U
in
> 95/190 V
Wide-range input
Yes
No
Overvoltage strength
2.3 × U
in rated
, 1.3 ms
Line failure buffering at
I
out rated
, min
25 ms 25 ms 20 ms 20 ms
Power-failure buffering at U
in
= 120/230 V,
typ. 150 ms for
U
in
= 500 V
at U
in
= 120/230 V,
typ. 150 ms for
U
in
= 500 V
at U
in
= 230 V at U
in
= 230 V
Rated line frequency
50 - 60 Hz
Line frequency range
47 - 63 Hz
Input current at rated
input voltage 120 V
2.2 A 4.4 A 7.7 A 15 A
Input current at rated
input voltage 230 V
1.2 A 2.4 A 3.5 A 8 A
Input current at rated
input voltage 500 V
0.61 A 1.1 A - -
Inrush current limiting
(25 °C), max.
35 A 35 A 60 A 125 A
I
2
t, max
1.7 A
2
s
4 A
2
s
9.9 A
2
s
26 A
2
s
