Safety, approvals, EMC
7.3 Approvals
SITOP modular 1ph/2ph
Manual, 04.2018, C98130-A7548-A1-4-7629
53
Table 7- 2 Test voltages for 6EP1336-3BA00 and 6EP1337-3BA00
Test time
Prim ↔ sec (A)
Prim ↔ PE (B)
Sec ↔ PE (C)
Type test
60 s
4200 V DC
2200 V DC
700 V DC
60 s 3000 V AC 1500 V AC 500 V AC
Production test
1 s
2200 V DC
2200 V DC
500 V DC
1 s 1500 V AC 1500 V AC 350 V AC
Field test
1 s
2200 V DC
2200 V DC
500 V DC
1 s
1500 V AC
1500 V AC
350 V AC
Remark:
Tripping current for DC measurement: 0
mA
Tripping current for AC measurement: < 100 mA
7.3
Approvals
6EP1333-3BA10 (24 V/5 A)
6EP1334-3BA10 (24 V/10 A)
6EP1336-3BA00 (24 V/20 A)
6EP1337-3BA00 (24 V/40 A)
CE marking
Yes, (2014/35/EU, 2014/30/EU, 2011/65/EU and 2014/34/EU)
CB approval
Yes
-
-
UL/cUL approval
cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259
cCSAus approval
cCSAus (CSA C22.2 No. 60950-1, UL 60950-1)
Explosion protection
Yes
Yes
Yes
ATEX approval II 3G Ex nA nC IIC T4 Gc
(EPS 14 ATEX 1 749 X)
II 3G Ex nA nC IIC T3 Gc
(EPS 12 ATEX 1 446 X)
II 3G Ex nA nC IIC T3 Gc
(EPS 12 ATEX 1 446 X)
IECex approval
Yes (IECEx EPS 14.0077X)
Yes (IECEx EPS 14.0066X)
Yes (IECEx EPS 14.0077X)
cCAus HazLoc Class I, Div 2, Group A,B,C,D
T4
- -
SEMI F47
Yes (IEC 61000-4-11)
Yes (IEC 61000-4-11)
Yes (IEC 61000-4-11)
Marine approvals
DNV GL, ABS
DNV GL, ABS
-
