Technical data
6.7 Mechanical system
SITOP modular 1ph/2ph
Manual, 04.2018, C98130-A7548-A1-4-7629
49
6.7
Mechanical system
6EP1333-3BA10
(24 V/5 A)
6EP1334-3BA10
(24 V/10 A)
6EP1336-3BA00
(24 V/20 A)
6EP1337-3BA00
(24 V/40 A)
Connection system
Screw-type terminal
Connections: Line input L1, N (L2), PE: 1
screw terminal each
for 0.05 - 4 mm² solid
(finely stranded)
L1, N (L2), PE: 1
screw terminal each
for 0.05 - 4 mm² solid
(finely stranded)
L1, N (L2), PE, Jump
120 V AC: 1 screw
terminal each for
0.2 - 6 (4) mm² solid
(finely stranded)
L1, N (L2), PE, Jump
120 V AC: 1 screw
terminal each for
0.2 - 6 (4) mm² solid
(finely stranded)
Connections: Output +, -: 2 screw terminals
each for
0.2 - 4 (2.5) mm² solid
(finely stranded)
+, -: 2 screw terminals
each for
0.2 - 4 (2.5) mm² solid
(finely stranded)
+, -: 2 screw terminals
each for
0.2 - 6 (4) mm² solid
(finely stranded)
+, -: 2 screw terminals
each for
0.5 - 16 (10) mm²
solid (finely stranded)
Connections: Auxiliary
contacts
Signaling contact: 1 screw terminal each for
0.14 ... 1.5 mm² solid (finely stranded)
- -
Width: of the enclosure
70 mm
70 mm
160 mm
240 mm
Height: of the enclosure
125 mm
125 mm
125 mm
125 mm
Depth: of the enclosure
121 mm
121 mm
121 mm
121 mm
Installation width
70 mm
70 mm
164 mm
244 mm
Mounting height
225 mm
225 mm
225 mm
225 mm
Weight, approx.
0.6 kg
0.8 kg
2.2 kg
2.9 kg
Product feature of the
housing: housing that can
be lined up next to one
another
Yes
Type of mounting: Rail
mounting
Yes
Mounting Can be snapped onto standard EN 60715 35x7,5/15 mounting rails Can be snapped onto
standard EN 60715
35x15 mounting rails
6.8
Accessories
6EP1333-3BA10 (24 V/5 A)
6EP1334-3BA10 (24 V/10 A)
6EP1336-3BA00 (24 V/20 A)
6EP1337-3BA00 (24 V/40 A)
Electrical accessories Functionality can be expanded using sup-
plementary modules – redundancy module,
buffer module, selectivity module and DC
USV.
Functionality can be expanded using sup-
plementary modules – signaling module,
redundancy module, buffer module, selec-
tivity module and DC USV.
