Siemens SITOP PSU200M 6EP1333-3BA10 User Manual

Technical data
6.2 Output
SITOP modular 1ph/2ph
Manual, 04.2018, C98130-A7548-A1-4-7629
39
6.2
Output
6EP1333-3BA10
(24 V/5 A)
6EP1334-3BA10
(24 V/10 A)
6EP1336-3BA00
(24 V/20 A)
6EP1337-3BA00
(24 V/40 A)
Output
Regulated, isolated DC voltage
Rated voltage U
out rated
DC
24 V
Total tolerance, static ±
3 %
3 %
3 %
3 %
Static line regulation, approx.
0.1 %
0.1 %
0.1 %
0.1 %
Static load regulation, approx.
0.1 %
0.1 %
0.1 %
0.1 %
Residual ripple in the load
range Peak-peak, max.
50 mV 50 mV 100 mV 100 mV
Spikes peak-peak, max.
(bandwidth, approx. 20 MHz)
200 mV 200 mV 200 mV 200 mV
Adjustment range
24 - 28.8 V
Output voltage can be adjusted
Yes
Output voltage setting
• Remark
Via potentiometer
Max. 120 W Max. 240 W Max. 480 W Max. 960 W
Output derating U
out
/T See Figure 6-7 Output derating depending on the ambient temperature at Iout rated
(Page 42)
Output derating U
out
/I
out
See Figure 6-8 Output derating depending on the output current at 60° C (Page 42)
Output derating U
out
/U
i
• Remark
- - - See Figure 6-9
Output derating
depending on the
input voltage
(Page 43)
For 85 to 93 V AC, it
is not permissible
that the output volt-
age is set higher
than 24 V.
Response when switching
on/off
U
out
overshoots by approximately 3 %
Starting delay, max.
1 s
1 s
0.1 s
0.1 s
Voltage rise, typ.
50 ms
50 ms
50 ms
50 ms
Rise time of the output voltage,
max.
500 ms 500 ms 500 ms 500 ms
Rated current I
out rated
5 A
10 A
20 A
40 A
Current range
• Remark
0 - 5 A 0 - 10 A
60 - 70 °C derating:
approx.
2 % I
out rated
/K
0 - 20 A
60 - 70 °C derating:
approx.
2 % I
out rated
/K
0 - 40 A
60 - 70 °C derating:
approx.
2 % I
out rated
/K
Active power output, typ.
120 W
240 W
480 W
960 W
Constant overload current for a
short circuit when powering up,
typ.
6 A 12 A 23 A 46 A
