Singer 20U109 User Manual

27
Zigzag Sewing Machine | Instruction Manual and Parts List
3.26
Figure 37
Buttonhole Foot ‘1’, Needle plate ‘2’
(Zigzag stitch) and Feed Dog ‘3’ are
used for buttonhole stitching.
(Figure
37)
Fittings for
Buttonhole
Stitching
606692(20U-109/109C/112/112C/309)
410192 541937-452 543979
606688(20U-109/109C/309)
606502(20U-112/112C)
606652(20U-109/109C/309)
606402(20U-112/112C)
3.27
Figure 38
Figure 39
The hem foot ‘1’, needle plate ‘2’
(Straight stitch) and feed dog ‘3’ can
turn and stitch a narrow hem in a
single operation as the following
condition. (Figure 38 and 39)
1. Needle position selector:
Center position
2. Stitch width regulate:
Straight stitch position.
Fittings for
Hem Sewing
1
1
2
2
3
3
