Singer 20U109 - Side Cover

33
Zigzag Sewing Machine | Instruction Manual and Parts List
6.1
Face Plate,
Arm Top
Cover and Arm
Side Cover
Components
109 109C 112 112C 309 910
11 606454 Bobbin winder bracket assembly 1 1 1 1 1 1
12 606637 Spring 1 1 1 1 1 1
13 606638 Friction o-ring 1 1 1 1 0 1
GO207-8 Friction o-ring 0 0 0 0 1 0
14 606452 Bobbin winder regulating plate 1 1 1 1 1 1
15 606453 Spring 1 1 1 1 1 1
16 606449 Spring 1 1 1 1 1 1
17 606451 Hinge stud 1 1 1 1 0 1
GS272-8 Hinge stud 0 0 0 0 1 0
18 606439 Set screw 1 1 1 1 1 1
19 550032 Bobbin winder lever assembly 1 1 1 1 0 1
20 544208-005 Bobbin winder lever set screw 1 1 1 1 0 1
21 606447 Bobbin winder lever stud 1 1 1 1 1 1
22 606448 Bobbin winder lever stud ring 1 1 1 1 0 1
GZ202-8 Bobbin winder lever stud ring 0 0 0 0 1 0
23 606446 Bobbi n winder regulator assembly 1 1 1 1 1 1
24 544208-005 Bobbin winder regulator screw 1 1 1 1 1 1
25 606639 Bobbin winder tension assembly 1 1 1 1 0 1
GR482/6-8 Bobbin winder tension assembly 0 0 0 0 1 0
26 606440 Bobbin winder tension stud 1 1 1 1 1 1
27 606442 Bobbin winder tension spring 1 1 1 1 1 1
28 606441 Bobbin winder tension disc 2 2 2 2 2 2
29 606443 Bobbin winder tension nut 1 1 1 1 0 1
GL162-8 Bobbin winder tension nut 0 0 0 0 1 0
30 606439 Screw 1 1 1 1 1 1
31 606602 Arm top cover screw 2 2 2 2 2 2
32 606398 Eccentric lock 1 1 1 1 0 1
GT150-8 Eccentric lock 0 0 0 0 1 0
33 606397 Eccentric screw 1 1 1 1 1 1
34 554128 Stopper pin 1 1 1 1 1 1
35 554144 Stopper spring 1 1 1 1 1 1
36 544212-001 Stopper screw 1 1 1 1 1 1
37 GK146-8 Thread take-up guard 0 0 0 0 1 0
38 GR406/-8 Face plate assembly 0 0 0 0 1 0
39 GR232-8 Thread guide 0 0 0 0 1 0
40 GS132-8 Screw 0 0 0 0 2 0
41 GR480/2-8 Bobbin winder lever assembly 0 0 0 0 1 0
42 J900112-001 Singer 'S' cameo 1 1 1 1 1 1
43 J900112-002 Singer logo resin plate (front) 1 1 1 1 1 1
44 J900112-003 Singer logo resin plate (back) 1 1 1 1 1 1
45 J900020-xxx Model plate 1 1 1 1 1 1
46 R03001 Rivet 6 6 6 6 6 6
No. Part No. Description
Qty
