Singer 20U109 User Manual

57
Zigzag Sewing Machine | Instruction Manual and Parts List
6.14
Thread Stand
Components
109 109C 112 112C 309 910
1 30102032 Thread bar (lower) 1 1 1 1 1 1
2 30128024 Washer 2 2 2 2 2 2
3 10128006 Rubber washer 1 1 1 1 1 1
4 N02001 Nut 1 1 1 1 1 1
5 30101029 Bracket (2 spools) 1 1 1 1 1 1
6 30103044 Spool holder 2 2 2 2 2 2
7 30102033 Spool pin 2 2 2 2 2 2
8 30123014 Cushion 2 2 2 2 2 2
9 30111007 Spool tray 2 2 2 2 2 2
10 W02002 Spring washer 2 2 2 2 2 2
11 N01005 Nut 2 2 2 2 2 2
12 L02004 Screw 1 1 1 1 1 1
13 N01004 Nut 4 4 4 4 4 4
14 S04002 Screw 4 4 4 4 4 4
15 30129005 Joint 1 1 1 1 1 1
16 30102034 Thread bar (upper) 1 1 1 1 1 1
17 30103045 Thread guide hole 2 2 2 2 2 2
18 30101031 Thread guide bar (2 spools) 1 1 1 1 1 1
20 30122027 Rod cap 1 1 1 1 1 1
No. Part No. Description
Qty
