Singer Stylist 7258 User Manual

17
更换机针
CHANGING THE NEEDLE
1. 逆时针转动手轮，提升针杆到最高位置。
2. 放松针夹螺钉。
3. 取下旧针。
4. 将新的针插入针夹中，针柄平面向后。
5. 沿槽向上推到顶。
6. 用螺钉起子拧紧针夹螺钉。
1. Raise the needle bar to its highest position by turning the hand
wheel toward you.
2. Loosen the needle clamp screw by turning it toward you.
3. Remove the needle by pulling it downward.
4. Insert the new needle into the needle clamp with the at side
toward the back.
5. Push the needle up as far as it can go.
6. Tighten the needle clamp screw rmly with the screw driver.
Always disconnect the machine from power supply by
removing the plug from the wall-outlet.
针柄平面
Flat side
限位销
Stop pin
针柄平面向后
Flat side toward the back
机针
Needle
注意：适当拧紧螺钉，但不要拧得过紧。
NOTE: Tighten snugly, but do not over tighten.
友情提示：在压脚下放一块碎布或一张纸，这样在换
机针时可避免机针掉入针板槽内。
Helpful Hint: Placing a scrap of fabric under the presser foot
and lowering the presser foot makes it easier to change the
needle and will preclude dropping the needle into the needle
plate slot.

Singer Stylist 7258 Specifications

General

Built-in Stitches	100
Buttonhole Styles	7
Stitch Width	7mm
Needle Positions	13
Speed Control	Yes
Automatic Needle Threader	Yes
LED Display	Yes
Free Arm	Yes
Weight	14.6 pounds
Type	Electronic
Bobbin System	Top Drop-In
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Maximum Stitch Width	7mm
Sewing Speed	750 stitches per minute
Drop Feed	Yes
LCD Screen	Yes
Presser Feet	All-Purpose Foot, Zipper Foot, Buttonhole Foot, Blind Hem Foot, Satin Stitch Foot
